OverviewTeaching: 300 min Exercises: 40 minQuestions
How do version control systems help reproducibility, and which systems should be used?Objectives
Become familiar with version control systems for code and data, as well as relevant tools based on them
Learn how to use version control systems to obtain, maintain and share code and data
Review available third party services and workflows that could be used to help to guarantee reproducibility of results
You can skip this lesson if you can answer these questions —>
- How do you keep all your scripts, configuration, notes and data under version control systems and shareable with your collaborators?
- How do you establish and use continuous integration systems to verify the correctness of reproduced results (where feasible)?
- What exactly have you done in your sample data analysis project X on a date Y?
We all probably do some level of version control with our files, documents, and even data files, but without a version control system (VCS) we do it in an ad-hoc manner:
So, in general, VCSs help track versions of digital artifacts such as code (scripts, source files), configuration files, images, documents, and data – both original or generated (as outcome of the analysis). With proper annotation of changes, a VCS becomes the lab notebook for changing content in the digital world. Since all versions are stored, VCS makes it possible to provide any previous version at any later point in time. You can thus see how it can be important for reproducing previous results – if your work’s history is stored in a VCS, you just need to get a previous version of your materials and carry out the analysis using it. You can also recover a file which you mistakenly removed since a previous version would be contained within your VCS, so no more excuses like “the cat ate my source code”. For those features alone it is worth placing any materials you produce and care about under some appropriate VCS.
Besides tracking changes, another main function of a VCS is collaboration. VCSs are typically used not only locally but across multiple hosts. Any modern VCS supports transfer and aggregation of versions of (or changes to) your work among collaborators. By using some public services (such as GitHub) you can also make them available to other online services (such as travis-ci) that can be configured to react to any new change you introduce and to perform prescribed actions. Integration with such services, which allows data to be automatically reanalyzed and verified for expected results, provides another big benefit for guaranteeing correct computations and reproducibility.
In this module we will first learn about
External teaching materials
To gain good general working knowledge of VCSs and Git, please go through the following lessons and a tutorial:
- Software Carpentry: Version Control with Git (full: 2:30h, familiarize: 20m) – a thorough lesson of the main git commands and workflows. Please complete the lesson until at least the
Licensingsubmodule, which will be a separate topic.
- Curious Git: A Curious Tale (full: 30m, familiarize: 10m) – useful read if you feel that “git internals” look like a black box to you. This example guides you through the principles of Git without talking about Git.
- (very optional, since this module is Git-based) Software Carpentry: Version Control with Mercurial (full: 4h)
On a new host, what is the recommended first step to set up Git?
It is recommended to configure Git so that commits have appropriate author information.
% git config --global user.name "FirstName LastName" % git config --global user.email "email@example.com"
Exercise: a basic Git/GitHub workflow
Goal: submit a pull request (PR) suggesting a change to the https://github.com/ReproNim/simple_workflow analysis. You should submit an initial PR with one of the changes, and then improve it with subsequent additional commits, and see how the PR gets automatically updated. Possible changes for the first commit to initiate a PR:
- a completely dummy change to README.md (0 points)
- a typo fix to README.md (10 points)
Then proceed to enact more meaningful change:
circle.ymlto run analysis (look for line with
run_demo_workflow.py) on just a single subject (currently
-n 2to run on two subjects)
Exercise: exploiting git history
Goal: determine how estimate for the Left-Amygdala changed in the AnnArbor_sub16960 subject from release 1.0.0 to 1.1.0.
git diff allows us to see the differences between points in the git history and to optionally restrict the search to the specific file(s), so the answers to the challenge were
% git diff 1.0.0..1.1.0 -- expected_output/AnnArbor_sub16960/segstats.json ... "Left-Amygdala": [ - 619, - 742.80002951622009 + 608, + 729.60002899169922 ],
As you have learned in the Remotes in GitHub section of the Software Carpentry Git course, the GitHub website provides you with public (or private) storage for your Git repositories on the web. The GitHub website also allows third-party websites to interact with your repositories to provide additional services, typically in a response to your submission of new changes to your repositories. Visit GitHub Marketplace for an overview of the vast collection of such additional services. Some services are free, some are “pay-for-service”. Students can benefit from obtaining a Student Developer Pack to gain free access to some services which otherwise would require a fee.
There is a growing number of online services providing continuous integration (CI) services. Although the free tier is unlikely to provide you with sufficient resources to carry out entire data analyses on your data, you are encouraged to use CIs. They can help verify your code’s reproducibility and correct execution, as well as the reproducibility of your results. CIs can be used on a set of unit-tests using “toy”/simulated data or on a subset of the real dataset. For example, see simple workflow code for a very simple, re-executable neuroimaging publication.
External teaching materials
- A quick Travis CI Tutorial for Node.js developers (full: 20m) a good description of all needed steps to perform to enable Travis CI for your GitHub project. Although tuned for Node.js projects, the same principles apply to other platforms/languages.
- Shablona - A template for small scientific python projects (review: 5m, optional) a template for scientific Python projects. Review its
.travis.ymlfor an example of a typical setup for a Python-based project.
- Travis CI Documentation (familiarize: 10m, canonical reference) ultimate documentation for Travis CI. Review sections of relevance to your language/platform.
External teaching materials
- CircleCI 1.0 Documentation (familiarize: 10m, canonical reference) ultimate documentation for CircleCI. Review sections of relevance to your language/platform.
External review materials
- Continuous Integration in the Cloud: Comparing Travis, Circle and Codeship (review: 10m) Having acquainted with the basics of those two CI offerings, review the differences
- Side-by-side comparison of CI services: review 5m
simple_workflowto execute sample analysis on another subject.
.git/annex/objects, into a file typically named according to the checksum of the file’s content, and in its place creates a symlink pointing to that new location
git-annexbranch, information is recorded regarding where (on which machine/clone or web URL) that data file is available from
Later on, if you have access to the clones of the repository that have the
copy of the file, you can easily
get it (which will download/copy that file
drop it (which will remove that file from
As a result of git not containing the actual content of those large files, but
instead containing just symlinks and information within the
git-annex branch, it
becomes possible to
git-annexbranch which would contain relevant information.
git merge a
git-annex branch. git-annex uses a special merge
algorithm to merge data availability information, and you should use
git annex merge
or git annex sync
commands to merge the
git-annex branch correctly.
External teaching materials
- git-annex walkthrough from a Cog Neuroscientist (full: 30 min): an IPython/Jupyter notebook. Please go through all the items, by either rerunning the notebook cells (if you have IPython/Jupyter available), or just copy/pasting them into a terminal
- git-annex walkthrough (full: 10 min): an original git-annex walkthrough. Go through all the sections to see which aspects previous walkthroughs did not cover.
- Another walk-through on a typical use-case for sync’ing, etc. (optional)
How can we get data files controlled by git-annex?
: Using git/git-annex commands
- “Download” a BIDS dataset from https://github.com/datalad/ds000114
getall non-preprocessed T1w anatomicals
- Try (and fail) to get all
- Knowing that
yoh@falkor:/srv/datasets.datalad.org/www/workshops/nipype-2017/ds000114is available via http from
http://datasets.datalad.org/workshops/nipype-2017/ds000114/.git, get those
% git clone https://github.com/datalad/ds000114 # 1. % cd ds000114 % git annex get sub-*/anat/sub-*_T1w.nii.gz # 2. % git annex get derivatives/freesurfer/sub-*/mri/T1.mgz # 3. (should fail) % git remote add datalad datasets.datalad.org/workshops/nipype-2017/ds000114/.git % git fetch datalad % git annex get derivatives/freesurfer/sub-*/mri/T1.mgz # 4. (should succeed)
How can we add the file a.txt directly under git, and file b.dat under git-annex?
Simple method (initial invocation)
git addfor adding files under Git, and
git annex addto add files under annex:
% git add a.txt % git annex add b.dat
Advanced method (for all future
git annex addcalls)
If you want to automate such “decision making” based on either files’ extensions and/or their sizes, you can specify those rules within a
.gitattributesfile (which in turn also needs to be
git add-ed), e.g.
% cat << EOF > .gitattributes * annex.largefiles=(not(mimetype=text/*)) *.dat annex.largefiles=anything EOF
would instruct the
git annex addcommand to add all non-text (according to the auto-detected MIME-type of their content) and all files having the
git-annexand the rest to git:
% git add .gitattributes # to add to git the new .gitattributes % git annex add a.txt b.dat
The DataLad project relies on Git and git-annex and establishes an integrated data monitoring, management and distribution environment. As a sample of a data distribution based on a number of “data crawlers” for existing data portals, it provides unified access to over 10TB of neural data from various initiatives (such as CRCNS, OpenfMRI, etc).
External teaching materials
- DataLad lecture and demo (Full: 55 min) This lecture describes the goals and basic principles of DataLad, and presents the first of the demos on discovery and installation of the datasets.
- DataLad demos of the features (Full: 30 min, review: 10 min) provides an asciinema (and shell script versions) introduction to major features of DataLad
- This example of a DataLad collaborative workflow (Full: 10 min) presents a simple workflow using DataLad to fully “version-control” data code in the project and collaborate efficiently
What DataLad command assists in recording the “effect” of running a command?
% datalad run COMMAND PARAMETERS
Please see datalad run –help for more details.
How can we create a new sub-dataset, populate it with derivative data, and share it?
Using DataLad commands, and starting with your existing clone of
ds000114from the preceding exercise:
- Create sub-dataset
- Using a skull-stripping tool (e.g.
betfrom FSL suite), for each original subject, produce a skull-stripped anatomical under its corresponding subdirectory of
derivatives/demo-bet. You are encouraged to use the
datalad runcommand (available in DataLad 0.9 or later) to leave a record on the action you took
- Publish your work to your “fork” of the repository on GitHub, while uploading data files to any data host you have available (ssh/http server, box.com, dropbox, etc)
% cd ds000114 % datalad create -d . derivatives/demo-bet # 1. % # a somewhat long but fully automated and "protocoled" by run solution: % datalad run 'for f in sub-*/anat/sub-*_T1w.nii.gz; do d=$(dirname $f); od=derivatives/demo-bet/$d; mkdir -p $od; bet $f derivatives/demo-bet/$f; done' # 2. % # establish a folder on box.com access to which would be shared in the group % export WEBDAV_USERNAME=secret WEBDAV_PASSWORD=secret % cd derivatives/demo-bet % # see https://git-annex.branchable.com/special_remotes for more supported git-annex special remotes % git annex initremote box.com type=webdav url=https://dav.box.com/dav/team/ds000114--demo-bet chunk=50mb encryption=none % datalad create-sibling-github --publish-depends box.com --access-protocol https ds000114--demo-bet % datalad publish --to github sub* %
sumatra - manages and tracks projects based on numerical simulation or analysis, with the aim of supporting reproducible research. It can be thought of as an “automated electronic lab notebook” for simulation/analysis projects.
noworkflow - captures a variety of provenance information and provides some analyses such as graph-based visualization, differencing over provenance trails, and inference queries.
etckeeper - a helper tool for
anyone administering their Linux-based system, which stores and
automatically commits any changes within
/etc into a VCS of your
choice. With its help you can track changes in your system
configuration, and that can be indispensable during system malfunction
Using VCS not only improves sharing and collaboration, but also is integral to assisting and guaranteeing reproducibility
VCS can be used directly or can serve a foundation for domain-specific tools
